Class

# Matrix

## Matrix()

2D Transformation Matrix.
Constructor

#### # new Matrix()

2D transformation matrix object initialized with identity matrix.
##### Properties:
Name Type Description
a number scale x
b number shear y
c number shear x
d number scale y
e number translate x
f number translate y
Version:
• 2.7.5
Author:
• Epistemex
License:
• MIT license (header required)

# Methods

#### #static from(a, bopt, copt, dopt, eopt, fopt, contextopt) → {Matrix}

Create and transform a new matrix based on given matrix values, or provide SVGMatrix or a (2D) DOMMatrix, WebKitCSSMatrix or another instance of a generic matrix.
##### Parameters:
Name Type Attributes Description
a * number representing a (scale x) in [a-f], or a Matrix object containing properties a-f.
b * <optional>
b property (shear y) if a is not a matrix object, or optional canvas 2D context. If vector is input this will be pre-translate for x.
c number <optional>
c property (shear x)
d number <optional>
d property (scale y)
e number <optional>
e property (translate x)
f number <optional>
f property (translate y)
context CanvasRenderingContext2D <optional>
optional canvas context to synchronize
- new Matrix instance
Matrix
##### Example
var m = Matrix.from(1, 0.2, 0, 2, 120, 97);
var m = Matrix.from(domMatrix, ctx);
var m = Matrix.from(svgMatrix);
var m = Matrix.from(matrix);

#### # applyToPoint(pt) → {Array.<number>}

Apply current matrix to `x` and `y` of a point. Returns a point object.
##### Parameters:
Name Type Description
pt Array.<number> the point to transform ([x, y]).
If an optionnal Z value is provided, it will be kept without transformation.
A new transformed point [x, y]. If pt had a third value, it is returned too, as it was without transformation.
Array.<number>

#### # clone(noContextopt) → {Matrix}

Clones current instance and returning a new matrix.
##### Parameters:
Name Type Attributes Default Description
noContext boolean <optional>
false don't clone context reference if true
- a new Matrix instance with identical transformations as this instance
Matrix

#### # decompose() → {*}

Decompose the current matrix into simple transforms using QR.
See:
- an object containing current decomposed values (translate, rotation, scale, skew)
*

#### # determinant() → {number}

Returns the determinant of the current matrix.
number

#### # inverse(cloneContextopt) → {Matrix}

Get an inverse matrix of current matrix. The method returns a new matrix with values you need to use to get to an identity matrix. Context from parent matrix is not applied to the returned matrix.
##### Parameters:
Name Type Attributes Default Description
cloneContext boolean <optional>
false clone current context to resulting matrix
Exception is input matrix is not invertible
- new Matrix instance
Matrix

#### # isEqual(m) → {boolean}

Compares current matrix with another matrix. Returns true if equal (within epsilon tolerance).
##### Parameters:
Name Type Description
m Matrix | Matrix | DOMMatrix | SVGMatrix matrix to compare this matrix with
boolean

#### # isIdentity() → {boolean}

Returns true if matrix is an identity matrix (no transforms applied).
boolean

#### # isInvertible() → {boolean}

Returns true if matrix is invertible
boolean

#### # isValid() → {boolean}

The method is intended for situations where scale is accumulated via multiplications, to detect situations where scale becomes "trapped" with a value of zero. And in which case scale must be set explicitly to a non-zero value.
boolean

#### # multiply(m) → {Matrix}

Multiplies current matrix with source matrix.
##### Parameters:
Name Type Description
m Matrix | Matrix | DOMMatrix | SVGMatrix source matrix to multiply with.
Matrix

#### # reset() → {Matrix}

Short-hand to reset current matrix to an identity matrix.
Matrix

#### # rotate(angle) → {Matrix}

Rotates current matrix by angle (accumulative).
##### Parameters:
Name Type Description
angle number angle in degrees
Matrix

#### # rotateFromVector(x, yopt) → {Matrix}

Converts a vector given as `x` and `y` to angle, and rotates (accumulative). x can instead contain an object with properties x and y and if so, y parameter will be ignored.
##### Parameters:
Name Type Attributes Description
x number | *
y number <optional>
Matrix

#### # scale(s) → {Matrix}

Scales current matrix accumulative.
##### Parameters:
Name Type Description
s Array.<number> scale factor [x, y]. 1 does nothing, any third value (Z) is ignored.
Matrix

#### # setTransform(a, b, c, d, e, f) → {Matrix}

Set current matrix to new absolute matrix.
##### Parameters:
Name Type Description
a number scale x
b number shear y
c number shear x
d number scale y
e number translate x
f number translate y
Matrix

#### # shear(sx, sy) → {Matrix}

Apply shear to the current matrix accumulative.
##### Parameters:
Name Type Description
sx number amount of shear for x
sy number amount of shear for y
Matrix

#### # skew(ax, ay) → {Matrix}

Apply skew to the current matrix accumulative. Angles in radians. Also see `skewDeg()`.
##### Parameters:
Name Type Description
ax number angle of skew for x
ay number angle of skew for y
Matrix

#### # toCSS() → {string}

Generates a string that can be used with CSS `transform`.
string
##### Example
element.style.transform = m.toCSS();

#### # toCSS3D() → {string}

Generates a `matrix3d()` string that can be used with CSS `transform`. Although the matrix is for 2D use you may see performance benefits on some devices using a 3D CSS transform instead of a 2D.
string
##### Example
element.style.transform = m.toCSS3D();

#### # toJSON() → {string}

Returns a JSON compatible string of current matrix.
string

#### # transform(a2, b2, c2, d2, e2, f2) → {Matrix}

Multiplies current matrix with new matrix values. Also see `multiply()`.
##### Parameters:
Name Type Description
a2 number scale x
b2 number skew y
c2 number skew x
d2 number scale y
e2 number translate x
f2 number translate y
Matrix

#### # translate(t) → {Matrix}

Translate current matrix accumulative.
##### Parameters:
Name Type Description
t Array.<number> translation [x, y]. Any third value (Z) is ignored.
Matrix
